The Century B2854V1 is a high-performance, up-rated replacement motor tailored for pool and spa applications. With a horsepower of 1.5 HP, dual-voltage (115/230 V) capability, and a square-flange (56Y) mounting frame, it offers broad compatibility with many existing pump systems. It delivers approximately 3450 RPM, draws 16.0/8.0 amps (115/230 V), and features a service factor of 1.10 (total HP 1.65).

Built with sealed ball bearings, a stainless-steel threaded shaft, and an open-drip-proof (ODP) enclosure, it is designed for durability and dependable operation. This motor supports continuous duty, making it a reliable choice for renovating pool circulation systems or replacing older motors.

Key Features:

• Genuine Century brand replacement motor
• 1.5 HP single-phase operation at 115/230 V
• 56Y frame with square-flange mounting for easy retrofits
• Approx. 3450 RPM speed, 16.0/8.0 amps (115/230 V)
• Service Factor: 1.10 for added load capacity
• ODP enclosure, sealed ball bearings, stainless-steel shaft for longevity
• Ideal for pool & spa pump systems
